Changing user formatting controls
block_formats
This option defines the formats to be displayed in the blocks
dropdown toolbar button and the blocks
menu item. Each item in the string should be separated by semi-colons and specified using the form title=block
.
Type: String
Default value: 'Paragraph=p; Heading 1=h1; Heading 2=h2; Heading 3=h3; Heading 4=h4; Heading 5=h5; Heading 6=h6;
default_font_stack
This option changes the default font stack that is considered as the "System Font" stack in the fontfamily toolbar and menu items. It’s should be an array of font family names that matches the default fonts in the the configured content_css CSS file.
Type: Array
Default value: [ '-apple-system', 'Segoe UI', 'Roboto', 'Helvetica Neue', 'sans-serif' ]
font_family_formats
This option defines the fonts to be displayed in the fontfamily
dropdown toolbar button and the fontfamily
menu item. Each item in the string should be separated by semi-colons and specified using the form of: title=font-family
.
Type: String
Default value:
'Andale Mono=andale mono,times; Arial=arial,helvetica,sans-serif; Arial Black=arial black,avant garde; Book Antiqua=book antiqua,palatino; Comic Sans MS=comic sans ms,sans-serif; Courier New=courier new,courier; Georgia=georgia,palatino; Helvetica=helvetica; Impact=impact,chicago; Symbol=symbol; Tahoma=tahoma,arial,helvetica,sans-serif; Terminal=terminal,monaco; Times New Roman=times new roman,times; Trebuchet MS=trebuchet ms,geneva; Verdana=verdana,geneva; Webdings=webdings; Wingdings=wingdings,zapf dingbats'
font_size_formats
This option allows you to override the font sizes displayed in the fontsize
dropdown toolbar button and the fontsize
menu item. Each item in the string should be space or comma-separated and include units.
Type: String
Default value: '8pt 10pt 12pt 14pt 18pt 24pt 36pt'
font_size_input_default_unit
This option sets the default unit of measure for typeface sizes as input in, for example, the fontsizeinput
toolbar button’s text-entry field.
Numbers entered in the fontsizeinput
toolbar without a qualifying unit of measure will be calculated using the unit of measure set.
Type: String
Default value: pt
Possible values: pt
, px
, em
, cm
, mm
If font_size_input_default_unit is set to an invalid value (ie, any string other than one of the possible values listed above), the setting is ignored. In such a case, numbers entered in the fontsizeinput toolbar without a qualifying unit of measure are also ignored.
|
line_height_formats
This option allows you to override the line heights displayed in the lineheight
dropdown toolbar button and the lineheight
menu item. Each item in the string should be space separated.
Type: String
Default value: '1 1.1 1.2 1.3 1.4 1.5 2'
indentation
This option allows specification of the indentation level for indent/outdent buttons in the UI.
The indentation option defaults to 30px but can be any value.
Type: String
Default value: '40px'
preview_styles
This option lets you configure the preview of styles in format/style listboxes. Enter a string with the styles that you wish to preview separated by a blankspace, or disable the preview of all styles by setting it to false
.
If unset the editor will preview the styles listed in the default value listed below.
Type: Boolean
or String
Default value: 'font-family font-size font-weight font-style text-decoration text-transform color background-color border border-radius outline text-shadow'
Possible values: String
, false
Example: using preview_styles
No preview of styles:
tinymce.init({
selector: 'textarea', // change this value according to your HTML
mode: 'textareas',
preview_styles: false
});
Preview of only font-size and color:
tinymce.init({
selector: 'textarea', // change this value according to your HTML
mode: 'textareas',
preview_styles: 'font-size color'
});
style_formats
This option allows you to define custom items for the styles
dropdown toolbar button and the styles
menu item.
There are four types of items the array can contain:
-
Style: The item must have a
title
and the necessary fields to specify a new format. An optionalname
can be provided for the style, which will be prefixed withcustom-
to ensure that it does not override the default editor formats. If given a uniquename
, the style can be used with the formatting API. The item will be rendered in the UI as a clickable item that applies the given format. -
Style reference: The item must have a
title
and aformat
which refers to a pre-registered editor format. The item will be rendered in the UI as a clickable item that applies the given format. -
Nested menu: The item must have a
title
and anitems
array that contains other items that will be rendered as a sub-menu. -
Group heading: The item must only have a
title
and will be rendered as a non-clickable heading within the menu. This is useful for grouping items without using nested menus.
To merge custom styles with the default styles_format
values, set style_formats_merge
to true
.
Type: Array
Default value: The following is the default value for style_formats
where it is using references to existing formats:
style_formats: [
{ title: 'Headings', items: [
{ title: 'Heading 1', format: 'h1' },
{ title: 'Heading 2', format: 'h2' },
{ title: 'Heading 3', format: 'h3' },
{ title: 'Heading 4', format: 'h4' },
{ title: 'Heading 5', format: 'h5' },
{ title: 'Heading 6', format: 'h6' }
]},
{ title: 'Inline', items: [
{ title: 'Bold', format: 'bold' },
{ title: 'Italic', format: 'italic' },
{ title: 'Underline', format: 'underline' },
{ title: 'Strikethrough', format: 'strikethrough' },
{ title: 'Superscript', format: 'superscript' },
{ title: 'Subscript', format: 'subscript' },
{ title: 'Code', format: 'code' }
]},
{ title: 'Blocks', items: [
{ title: 'Paragraph', format: 'p' },
{ title: 'Blockquote', format: 'blockquote' },
{ title: 'Div', format: 'div' },
{ title: 'Pre', format: 'pre' }
]},
{ title: 'Align', items: [
{ title: 'Left', format: 'alignleft' },
{ title: 'Center', format: 'aligncenter' },
{ title: 'Right', format: 'alignright' },
{ title: 'Justify', format: 'alignjustify' }
]}
]
Example: using style_formats
This example shows how to append 3 new style formats.
tinymce.init({
selector: 'textarea', // change this value according to your HTML
style_formats: [
{ title: 'Bold text', inline: 'b' },
{ title: 'Red text', inline: 'span', styles: { color: '#ff0000' } },
{ name: 'my-inline', title: 'My inline', inline: 'span', classes: [ 'my-inline' ] }
],
// The following option is used to append style formats rather than overwrite the default style formats.
style_formats_merge: true
});
Interactive examples
This example shows you how to:
-
Override the built-in formats.
-
Add some custom styles to the
styles
dropdown toolbar button and thestyles
menu item using the style_formats configuration option.
-
TinyMCE
-
HTML
-
JS
-
Edit on CodePen
<textarea id="format-custom">
<p><img style="display: block; margin-left: auto; margin-right: auto;" title="Tiny Logo" src="https://www.tiny.cloud/docs/images/logos/android-chrome-256x256.png" alt="TinyMCE Logo" width="128" height="128"></p>
<h2>Welcome to the TinyMCE editor demo!</h2>
<p>
Please try out the features provided in this custom formats example.
</p>
<h2>Got questions or need help?</h2>
<ul>
<li>Our <a href="https://www.tiny.cloud/docs/tinymce/6/">documentation</a> is a great resource for learning how to configure TinyMCE.</li>
<li>Have a specific question? Try the <a href="https://stackoverflow.com/questions/tagged/tinymce" target="_blank" rel="noopener"><code>tinymce</code> tag at Stack Overflow</a>.</li>
<li>We also offer enterprise grade support as part of <a href="https://www.tiny.cloud/pricing">TinyMCE premium plans</a>.</li>
</ul>
<h2>A simple table to play with</h2>
<table style="border-collapse: collapse; width: 100%;" border="1">
<thead>
<tr>
<th>Product</th>
<th>Cost</th>
<th>Really?</th>
</tr>
</thead>
<tbody>
<tr>
<td>TinyMCE</td>
<td>Free</td>
<td>YES!</td>
</tr>
<tr>
<td>Plupload</td>
<td>Free</td>
<td>YES!</td>
</tr>
</tbody>
</table>
<h2>Found a bug?</h2>
<p>
If you think you have found a bug please create an issue on the <a href="https://github.com/tinymce/tinymce/issues">GitHub repo</a> to report it to the developers.
</p>
<h2>Finally ...</h2>
<p>
Don't forget to check out our other product <a href="http://www.plupload.com" target="_blank">Plupload</a>, your ultimate upload solution featuring HTML5 upload support.
</p>
<p>
Thanks for supporting TinyMCE! We hope it helps you and your users create great content.<br>All the best from the TinyMCE team.
</p>
</textarea>
tinymce.init({
selector: 'textarea#format-custom',
height: 500,
plugins: 'table wordcount',
content_style: '.left { text-align: left; } ' +
'img.left, audio.left, video.left { float: left; } ' +
'table.left { margin-left: 0px; margin-right: auto; } ' +
'.right { text-align: right; } ' +
'img.right, audio.right, video.right { float: right; } ' +
'table.right { margin-left: auto; margin-right: 0px; } ' +
'.center { text-align: center; } ' +
'img.center, audio.center, video.center { display: block; margin: 0 auto; } ' +
'table.center { margin: 0 auto; } ' +
'.full { text-align: justify; } ' +
'img.full, audio.full, video.full { display: block; margin: 0 auto; } ' +
'table.full { margin: 0 auto; } ' +
'.bold { font-weight: bold; } ' +
'.italic { font-style: italic; } ' +
'.underline { text-decoration: underline; } ' +
'.example1 {} ' +
'body { font-family:Helvetica,Arial,sans-serif; font-size:16px }' +
'.tablerow1 { background-color: #D3D3D3; }',
formats: {
alignleft: { selector: 'p,h1,h2,h3,h4,h5,h6,td,th,div,ul,ol,li,table,img,audio,video', classes: 'left' },
aligncenter: { selector: 'p,h1,h2,h3,h4,h5,h6,td,th,div,ul,ol,li,table,img,audio,video', classes: 'center' },
alignright: { selector: 'p,h1,h2,h3,h4,h5,h6,td,th,div,ul,ol,li,table,img,audio,video', classes: 'right' },
alignfull: { selector: 'p,h1,h2,h3,h4,h5,h6,td,th,div,ul,ol,li,table,img,audio,video', classes: 'full' },
bold: { inline: 'span', classes: 'bold' },
italic: { inline: 'span', classes: 'italic' },
underline: { inline: 'span', classes: 'underline', exact: true },
strikethrough: { inline: 'del' },
customformat: { inline: 'span', styles: { color: '#00ff00', fontSize: '20px' }, attributes: { title: 'My custom format'} , classes: 'example1'}
},
style_formats: [
{ title: 'Custom format', format: 'customformat' },
{ title: 'Align left', format: 'alignleft' },
{ title: 'Align center', format: 'aligncenter' },
{ title: 'Align right', format: 'alignright' },
{ title: 'Align full', format: 'alignfull' },
{ title: 'Bold text', inline: 'strong' },
{ title: 'Red text', inline: 'span', styles: { color: '#ff0000' } },
{ title: 'Red header', block: 'h1', styles: { color: '#ff0000' } },
{ title: 'Badge', inline: 'span', styles: { display: 'inline-block', border: '1px solid #2276d2', 'border-radius': '5px', padding: '2px 5px', margin: '0 2px', color: '#2276d2' } },
{ title: 'Table row 1', selector: 'tr', classes: 'tablerow1' },
{ title: 'Image formats' },
{ title: 'Image Left', selector: 'img', styles: { 'float': 'left', 'margin': '0 10px 0 10px' } },
{ title: 'Image Right', selector: 'img', styles: { 'float': 'right', 'margin': '0 0 10px 10px' } },
]
});
This example shows you how to edit HTML5 content such as sections and articles.
-
TinyMCE
-
HTML
-
JS
-
Edit on CodePen
<textarea id="format-html5">
<section>
Section
<p>Paragraph</p>
</section>
<article>
Article
<p>Paragraph</p>
</article>
<blockquote>
Blockquote
<p>Paragraph</p>
</blockquote>
<aside>
Section
<p>Paragraph</p>
</aside>
<figure>
Figure
<figcaption>Figcaption</figcaption>
</figure>
</textarea>
tinymce.init({
selector: 'textarea#format-html5',
height: 500,
plugins: 'visualblocks',
style_formats: [
{ title: 'Headers', items: [
{ title: 'h1', block: 'h1' },
{ title: 'h2', block: 'h2' },
{ title: 'h3', block: 'h3' },
{ title: 'h4', block: 'h4' },
{ title: 'h5', block: 'h5' },
{ title: 'h6', block: 'h6' }
] },
{ title: 'Blocks', items: [
{ title: 'p', block: 'p' },
{ title: 'div', block: 'div' },
{ title: 'pre', block: 'pre' }
] },
{ title: 'Containers', items: [
{ title: 'section', block: 'section', wrapper: true, merge_siblings: false },
{ title: 'article', block: 'article', wrapper: true, merge_siblings: false },
{ title: 'blockquote', block: 'blockquote', wrapper: true },
{ title: 'hgroup', block: 'hgroup', wrapper: true },
{ title: 'aside', block: 'aside', wrapper: true },
{ title: 'figure', block: 'figure', wrapper: true }
] }
],
visualblocks_default_state: true,
end_container_on_empty_block: true,
content_style: 'body { font-family:Helvetica,Arial,sans-serif; font-size:16px }'
});
style_formats_autohide
This option enables auto hiding of styles that can’t be applied to the current context. For example: if a style applies only to tables, it wouldn’t be visible in the styles drop down when the caret isn’t inside a table. By default, irrelevant menu items are disabled
Type: Boolean
Default value: false
style_formats_merge
This option allows you to set whether TinyMCE should append custom styles defined using the style_formats
setting to the default style formats or completely replace them.
Type: Boolean
Default value: false
Text color options
These options affect the color selector shown when using the forecolor
(text color) and backcolor
(text background) toolbar buttons or menu items. The dimensions and mapping of the grid of text colors can be set here.
color_cols
This option allows for specifying the number of columns for text color grids. The number of rows is calculated based on the number of text colors supplied divided by the specified number of columns.
By default, the number of rows and columns is dependent of the number of colors specified using color_map
. The dimensions of the grid will be calculated by TinyMCE to keep the grid a square or a rectangle with a minimum of 5 columns.
Type: Integer
color_cols_background
This option specifies the number of columns for background text color grids.
If color_cols_background
is not set, the number of columns a highlight color grid takes is set by the color_cols
option.
If both color_cols
and color_cols_background
options are set, the color_cols_background
value is used.
If neither color_cols
nor color_cols_background
options are set, the highlight color grid presents with the default number of columns, 5.
Type: Number
Default value: 5
Example: using color_cols_background
This example sets the number of columns in the default color grid to 10 then sets the background text color grid to display 3 columns.
tinymce.init({
selector: 'textarea', // change this value according to your html
toolbar: 'backcolor forecolor',
color_cols: 10,
color_cols_background: 3,
});
color_cols_foreground
This option specifies the number of columns for foreground text color grids.
If color_cols_foreground
is not set, the number of columns a foreground text color grid takes is set by the color_cols
option.
If both color_cols
and color_cols_foreground
options are set, the color_cols_foreground
value is used.
If neither color_cols
nor color_cols_foreground
options are set, text color grid presents with the default number of columns, 5.
Type: Integer
Default value: 5
Example: using color_cols_foreground
This example sets the number of columns in the default color grid to 10 then sets the foreground text color grid to display 3 columns.
tinymce.init({
selector: 'textarea', // change this value according to your html
toolbar: 'backcolor forecolor',
color_cols: 10,
color_cols_foreground: 3,
});
color_map
This option allows for specifying a map of the text colors that will appear in the grid.
Colors are added to the array with a Hex or RGB color value, followed by the name of that color as it would appear in the color grid when hovered over. Both values are required for each color added to the color map.
Type: Array
Example: using color_map
tinymce.init({
selector: 'textarea', // change this value according to your HTML
toolbar: 'forecolor backcolor',
color_map: [
'000000', 'Black',
'808080', 'Gray',
'FFFFFF', 'White',
'FF0000', 'Red',
'FFFF00', 'Yellow',
'008000', 'Green',
'0000FF', 'Blue'
]
});
If color_map
is not explicitly set, TinyMCE populates color grids with a default set of 22 colors.
Example: explicitly setting color_map
to the default TinyMCE color set
tinymce.init({
selector: 'textarea', // change this value according to your HTML
toolbar: 'forecolor backcolor',
color_map: [
'#BFEDD2', 'Light Green',
'#FBEEB8', 'Light Yellow',
'#F8CAC6', 'Light Red',
'#ECCAFA', 'Light Purple',
'#C2E0F4', 'Light Blue',
'#2DC26B', 'Green',
'#F1C40F', 'Yellow',
'#E03E2D', 'Red',
'#B96AD9', 'Purple',
'#3598DB', 'Blue',
'#169179', 'Dark Turquoise',
'#E67E23', 'Orange',
'#BA372A', 'Dark Red',
'#843FA1', 'Dark Purple',
'#236FA1', 'Dark Blue',
'#ECF0F1', 'Light Gray',
'#CED4D9', 'Medium Gray',
'#95A5A6', 'Gray',
'#7E8C8D', 'Dark Gray',
'#34495E', 'Navy Blue',
'#000000', 'Black',
'#ffffff', 'White'
]
});
color_map_raw
The color_map_raw
option specifies a map of text colors that appear in the color picker grid. This configuration provides detailed control over the colors available for the forecolor
and backcolor
toolbar options. The following example shows how to set the color map using CSS variables, color functions, and hex codes.
Type: Array
Example: using color_map_raw
tinymce.init({
selector: 'textarea', // Adjust this value according to your HTML
toolbar: 'forecolor backcolor',
color_map_raw: [
'var(--black)', 'Black', // CSS variable-based colors
'var(--red)', 'Red',
'hsb(0, 100%, 100%)', 'White hsb', // Color functions like hsb() and hsl()
'hsl(0, 100%, 50%)', 'Red hsl',
'#ff00ff', 'Pink', // Hex code-based colors
'#00ffff', 'Cyan',
'var(--purple)', 'Purple', // User-friendly labels for easy identification such as 'Purple'.
'#00FF7F', 'Spring Green'
],
});
color_map_background
This option allows for specifying a map of the text colors that will appear in the highlight color grid.
If it is not set, the highlight color grid takes it values from the color_map
array.
And, if the color_map
array is, further, not set, the highlight color grid takes it values from the TinyMCE default color set.
That is, the highlight grid takes its values in the following priority order:
-
a set
color_map_background
color array is used in preference to -
a set
color_map
color array, which is used in preference to -
the default TinyMCE color array.
Type: Array
Example: using color_map_background
tinymce.init({
selector: 'textarea', // change this value according to your html
toolbar: 'forecolor backcolor',
color_map_background: [
'000000', 'Black',
'808080', 'Gray',
'FFFFFF', 'White',
'FF0000', 'Red',
'FFFF00', 'Yellow',
'008000', 'Green',
'0000FF', 'Blue'
]
});
color_map_foreground
This option allows for specifying a list of the text colors that will appear in the text color grid.
If it is not set, the text color grid takes it values from the set color_map
array.
And, if the color_map
array is, further, not set, the text color grid takes it values from the TinyMCE default color set.
That is, the text color grid takes its values in the following priority order:
-
a set
color_map_foreground
color array is used in preference to -
a set
color_map
color array, which is used in preference to -
the default TinyMCE color array.
Type: Array
Example: using color_map_foreground
tinymce.init({
selector: 'textarea', // change this value according to your html
toolbar: 'forecolor backcolor',
color_map_foreground: [
'000000', 'Black',
'808080', 'Gray',
'FFFFFF', 'White',
'FF0000', 'Red',
'FFFF00', 'Yellow',
'008000', 'Green',
'0000FF', 'Blue'
]
});
When end-users add a new custom color via a text color grid, that color is added to the associated text color grid but the new custom color is only held in the host browser’s local storage. If, for example, an end-user adds a custom color to the foreground text color grid, that new color is presented in the foreground text color grid in the end-user’s {productname} instance. The new custom color is not, however, stored in any of the instance’s color map arrays. Also, when a user adds a custom color to one palette (for example, the `color_map_background` palette), the {productname} editor instance does not replicate the new custom color in the complementary palette (for example, the `color_map_foreground` palette).
color_default_background
This option allows the user to replace the background
default color for the toolbar buttons and menu items.
Once set, the background color for the toolbar button will then render the new color set in the color_default_background
options. This will then apply the new background
color to any text that has been selected after the button is pressed.
Assuming a color_map
is also set (and it is set by default) other colors in the color_map
are visible by opening the backcolor
toolbar’s menu.
Type: String
color_default_foreground
This option allows the user to replace the foreground
default color for the toolbar buttons and menu items.
Once set, the foreground color for the toolbar button will then render the new color set in the color_default_foreground
options. This will then apply the new foreground
color to any text that has been selected after the button is pressed.
Assuming a color_map
is also set (and it is set by default) other colors in the color_map
are visible by opening the forecolor
toolbar’s menu.
Type: String
Example: using color_default_foreground
tinymce.init({
selector: "textarea", // change this value according to your html
toolbar: 'forecolor',
color_default_foreground: 'red',
});
The default color_map
color_map: [
'#BFEDD2', 'Light Green',
'#FBEEB8', 'Light Yellow',
'#F8CAC6', 'Light Red',
'#ECCAFA', 'Light Purple',
'#C2E0F4', 'Light Blue',
'#2DC26B', 'Green',
'#F1C40F', 'Yellow',
'#E03E2D', 'Red',
'#B96AD9', 'Purple',
'#3598DB', 'Blue',
'#169179', 'Dark Turquoise',
'#E67E23', 'Orange',
'#BA372A', 'Dark Red',
'#843FA1', 'Dark Purple',
'#236FA1', 'Dark Blue',
'#ECF0F1', 'Light Gray',
'#CED4D9', 'Medium Gray',
'#95A5A6', 'Gray',
'#7E8C8D', 'Dark Gray',
'#34495E', 'Navy Blue',
'#000000', 'Black',
'#ffffff', 'White'
]
